Vectaire Elix ELX1003DTLV 4" (100mm) Centrifugal Continuous Extract Fan (Low Volt) SELV

Vectaire Elix ELX1003DTLV 4" (100mm) Centrifugal Continuous Extract Fan (Low Volt) SELV

  • £164.00


  • energy efficient EC motor
  • provides low level continuous ventilation to control condensation
  • 3 speed centrifugal fan
  • choice of 2 low speeds at installation
  • for wall or ceiling
  • for any domestic wet room
  • low noise levels and running costs
  • compliant with Building Regulations Parts L1 2010 and F 2010

General

  • exhausts directly to the outside or through long lengths of ducting (up to 15m)
  • runs continuously at pre-selected choice of two speeds (fixed at installation)
  • Speed 1 operates at 8 l/s (factory set)
  • Speed 2 operates at 14 l/s
  • anti-vibration gasket
  • easily removal, washable polypropylene filter
  • speed boosted to maximum (28 l/s) using integral pull cord or by:
    • remote switch/light switch
    • PIR sensor
    • DRH240 (dynamic remote humidistat)
  • energy saving ventilation
  • extremely low running costs
  • low carbon footprint
  • 2 year warranty
  • ELX1003DTLV - 3 speed, continuous running, with comfort timer, overrun timer and pull-cord LOW VOLT (SELV)

Specification

  • shockproof, high quality technopolymer casing
  • designed using latest wind tunnel technology and CFD simulations
  • profile increases the fluid dynamics
  • EC induction motor with thermal protection
  • 30,000 hour life motors with maintenance free and long life ball bearings
  • operates in ambient temperatures up to 40ºC
  • double insulated - no earth required
  • IPX4 - Splashproof rated - can safely be installed in Zones I and II

Compliance

  • Part L1 2010 of Building Regulations for enhanced energy saving capability
  • Part F 2010 of Building Regulations for reliable, efficient ventilation
  • IEC 60335-2-80, BT 2006/95/CE and EMC 2004/108/CE European Directive against radio interference and electro-magnetic compatibility
  • CE marked
  • SAP Q eligible
  • Energy Saving Trust Best Practice Compliant
